DIN ball valves
Reliable
DIN ball valves for industry
DIN ball valves
As a quality supplier of industrial valves in accordance with DIN EN and ASME, we offer you an extensive
product range of valves of all types. Our portfolio includes valves in a wide range of pressure ratings and materials
as well as complete system solutions. Our products are optimized for industrial applications.
DIN stainless steel ball valves, soft-seated, for chemicals
Fig.751
- Nominal size: DN15 to DN200
- Pressure: PN10 to PN40
- Temperature: -50℃ to +260℃
- Housing material: 1.4408, 1.4308, 1.4581, 1.4470, 1.0619, 1.6220, 1.7357, 1.7379
- Connection ends: Flanges according to EN 1092-1
- Certificate: TA Luft, ISO 15848-1, API 607
- Application: chemical, petrochemical, pharmaceutical industry, water
- Fig.133/135/153/155.751
- Data sheet 751
DIN 3-part ball valves, soft-seated
Fig.752
- Nominal size: DN15 to DN150
- Pressure: PN10 to PN40
- Temperature: -50℃ to +260℃
- Housing material: 1.4408, 1.4308, 1.4581, 1.4470, 1.0619, 1.6220, 1.7357, 1.7379
- Connection ends: Flanges according to EN 1092-1
- Certificate: TA Luft, ISO 15848-1, API 607
- Application: chemical, petrochemical, pharmaceutical industry, water
- Fig.133/135/153/155.752
- Data sheet 752
DIN stainless steel ball valves, metal-seated
Fig.753
- Nominal size: DN15 to DN200
- Pressure: PN10 to PN40
- Temperature: -60℃ to +400℃
- Housing material: 1.4408, 1.4308, 1.4581, 1.4470, 1.0619, 1.6220, 1.7357, 1.7379
- Connection ends: Flanges according to EN 1092-1
- Certificate: TA Luft, ISO 15848-1, API 607
- Application: chemical, petrochemical, pharmaceutical industry, water
- Fig.133/135/153/155.753
- Data sheet 753
DIN stainless steel ball valves, soft-seated with disk spring on the seat
Fig.754
- Nominal size: DN15 to DN200
- Pressure: PN10 to PN40
- Temperature: -50℃ to +260℃
- Housing material: 1.4408, 1.4308, 1.4581, 1.4470, 1.0619, 1.6220, 1.7357, 1.7379
- Connection ends: Flanges according to EN 1092-1
- Certificate: TA Luft, ISO 15848-1, API 607
- Application: chemical, petrochemical, pharmaceutical industry, water
- Fig.133/135/153/155.754
- Data sheet 754
DIN steel and stainless steel ball valves, with internally mounted ball
Fig.761
- Nominal diameter: DN150 to DN300
- Pressure: PN10 to PN40
- Temperature: -50℃ to +260℃
- Housing material: 1.4408, 1.4308, 1.4581, 1.4470, 1.0619, 1.6220, 1.7357, 1.7379
- Connection ends: Flanges according to EN 1092-1
- Certificate: TA Luft, ISO 15848-1, API 607
- Application: chemical, petrochemical, pharmaceutical industry, water
- Fig.133/135/153/155.761
- Data sheet 761
DIN steel and stainless steel compact flanged ball valves, soft-seated
Fig.764
- Nominal size: DN15 to DN150
- Pressure: PN10 to PN40
- Temperature: -50℃ to +260℃
- Housing material: 1.4408, 1.4308, 1.4581, 1.4470, 1.0619, 1.6220, 1.7357, 1.7379
- Connection ends: Flanges according to EN 1092-1
- Certificate: TA Luft, ISO 15848-1, API 607
- Application: chemical, petrochemical, pharmaceutical industry, water
- Fig.133/135/153/155.764
- Data sheet 764
